Omron E5CK-AA1-500 Digital Temperature Controller with Panel Retainer Mount

OMRON

$169.00

Web Information

Omron E5CK-AA1-500 Digital Temperature Controller

Specifications

Input Type : Analogue Current⁄Voltage
IP Rating : IP00 (Terminal), IP20 (Rear Case), IP66 (Front Panel)
Maximum Operating Temperature : +55 °C
Minimum Operating Temperature : -10 °C
Mounting Type : Panel Mount
Number of Inputs : 1
Number of Outputs : 1
Operating Temperature Range : -10 to +55 °C
Panel Depth : 100 mm
Series : E5CK Series
Size : 53 x 53 mm
Supply Voltage : 100 to 240 VAC
Termination Type : Screw

Overview

Features:
  • Advanced PID and Fuzzy Self-Tuning
  • Field Configurable Output Options (Relay, SSR, Pulse, Linear) — Choose Two (2)
  • Set-Point Ramp/Heat Only or Heat/Cool Control
  • Front-Panel Programming
  • Auxiliary Output: Relay — SPST-NO 3 A @ 250 VAC (Standard)
  • Serial Communications Available
  • UL/CSA/CE Approved

    Specifications:
  • Supply Voltage: 100-240 VAC/24 VAC/VDC
  • Thermocouple Inputs: K, J, T, E, L, U, N, R, S, B, W
  • Platinum RTD Input: Pt100 and JPt100
  • Current Input: 4 to 20 mA DC, 0 to 20 mA DC
  • Voltage Input: 1 to 5 VDC, 0 to 5 VDC, 0 to 10 VDC
  • Control Output: SPST-NO 3 A @ 250 VAC/SSR 1 A @ 75 to 250 VAC

Condition

Seller refurbished. The item is tested and is in excellent working condition.

Includes

  • Omron E5CK-AA1-500 Digital Temperature Controller
  • Panel Retainer Mount

LRGS

Warranty

30 Day warranty. We pledge to offer the best service and warranty to all of our customers! We are extending a 30 Day warranty on this item. This is our way of saying thank you for allowing us to serve you.

Certification

This is a genuine product from this manufacturer.
